Leadenhall Office Building in UK
Main glass makeup: 6mm clear glass blue(or red) strip frit HS (#2)(outside)+1.52PVB+6mm
SunGuard HS SN51/28 -LOW-E (#4)+16AR+6mm clear glass+0.38 clear PVB+0.38 milky
PVB+6mm clear glass
Total sqm: 8000sqm
Three Quays in UK
Main glass makeup: 10C FT w/HST SunGE05VT 2# w/black frit on edge+16Ar+6 C
Total sqm: 5000sqm
Manchester Town Hall in UK
Glass makeup: 3*12mm low iron glass curved tempered HST+2*1.52mmSGP
Total sqm: 400sqm, 8m height curved glass with big top and bottom stainless steel shoes
Bloomberg place in London,UK
Glass makeup: 12mm Serrated Annealed Low-Iron Glass heat treated + 2.66mm interlayer
(included 0.38mm sand white) + 8mm SunGuard SN 51/28 HT HS #4 + 16A TIG +6mm
Low-Iron hs+ 1.52mm PVB+ 6mm Low-Iron HS
Total sqm: 160sqm
Van Gogh Museum in Amsterdam
Glass makeup: 3*12 or 15mm low iron FT HST+ 2*1.78SGP
Total sqm: 250sqm, 12m height roof and façade fin glass
One Blackfriars in London
Main glass makeup: 6mm low iron SunGuard silver 70HD #2 HS +1.52PVB+6mm low iron
SunGuard silver 70HD #3 HS, curved glass with radius from 2m-13m
Total sqm: 18000sqm, #2 & #3 surface are both with coating, need to concave and convex curved
Manulife in Canada
Main glass makeup: 8mm low iron heat strengthened glass+1.52PVB+8mm low iron
heat strengthened glass OPTISOLAR US50II low-E coating on surface
#4+12Ar+8mm low iron heat strengthened glass +12Ar+8mm low iron heat
strengthened glass +8mm low iron tempered Optilite US83 low-E coating on
Total sqm: 20000sqm
Address: Calgary, Alberta, Canada
1. Roller wave should control within 0.125mm/300mm, BNG special tempering
performance for roller wave.
2. Irregular curved glass, min radius 1530mm, max height 4500mm.
3. High reflective coating request very small deformation.
Beautiful Waterfull in Beijing, China
Main glass makeup: 8mm grey tinted curved tempered glass + 16Ar + 8mm low
iron tempered US83 low-e #3
Total sqm: 24000sqm
Address: Liu-li-tun Chaoyang District, Beijing, China
1. All glass is irregular.
2. Each glass piece features a radius of 3.7m to 45m.
3. Every piece of glass has a different axis, not symmetrical.
4. Irregular glass is easily twisted, especially for 3 or 4 meter radius glass
5. 2 or 4 pieces glass need to be assembled in one unit.
6. Curved tempered glass without a straight edge.
